| 產品內容
Passive cable with E-Marker function & long length design up to 0.8m @ TBT3 mode
Supports 2-CH TBT Gen2 or TBT Gen3 full duplex high speed transmission
Supports 1-CH USB3.1 Gen1 or Gen2 full duplex high speed transmission
Supports 1-CH USB2.0 half duplex transmission
Support 4-lane DisplayPort video signal transmission, DP alternate mode
Dual-protocol support for TBT mode (PCI Express and DisplayPort) and can be used for daisy-chaining devices
Plug flip-able use
Thin cable design, OD=4.6mm
Compliant with USB Power Delivery Specification Rev3.0. Maximum power delivery capacity up to 5A
| 產品規格
General Specification
Length: 0.7-meter
Connector: LOTES Type-C connector or compatible
Color: Black
Electrical Specification
Transmission data rate: TBT: 2-lane TBT Gen2* or TBT Gen3* full duplex operation. USB: 1-lane USB2.0 half duplex operation, 1-CH USB3.1 Gen1 or Gen2 full duplex operation.
Operating Voltages: VBUS: 5V – 20V (typ.), VCONN: 5.5V(max) ~ 3.0V (min.)
Power consumption: under 20mW.(@ no PD traffic).
Current delivery capacity: 5A (max.)
Compliant with USB Power Delivery Specification Rev3.0
Storage and Operation temperature
Storage Temperature: Intel Thunderbolt Standard -20~85°C ambient.
Operation Temperature: Intel Thunderbolt Standard 0~50°C ambient.
