Supports TBT Gen3, Gen4 or Gen5 full duplex high speed transmission.
Supports USB4 Gen2/Gen3/Gen4 full duplex high speed transmission.
Supports 1-CH USB3.2 Gen1 or Gen2 or supports 2- CH USB3.2 Gen2 full duplex high speed transmission.
Supports 1-CH USB2.0 half duplex transmission.
Support DP2.1, 4-lane DisplayPort video signal transmission, DP alternate mode.
Dual-protocol support for TBT mode (PCI Express and DisplayPort) and can be used for daisy-chaining devices.
Triple -protocol support for USB4 mode (USB, PCI Express and DisplayPort*) and can be used for USB4 daisy-chaining devices.
Plug flip-able use.
Thin cable design, OD=5.1mm
Compliant with USB Power Delivery Specification Rev3.1 Maximum power delivery capacity up to 5A.
| 產品規格
General Specification
Length: 1.2-meter
Connector:Type-C connector or compatible
Color: Black / White
Electrical Specification
Transmission data rate:
Thunderbolt: Thunderbolt Gen2/Gen3/Gen4/Gen5 full duplex operation.
DP: DP2.1, 4-lane DisplayPort video signal transmission, DP alternate mode (MFDP).
USB:
1-CH USB3.2 Gen1 or Gen2 full duplex operation.
2-CH USB3.2 Gen2 full duplex operation.
USB4 Gen2/Gen3/Gen4 full duplex operation.
CH USB2.0 half duplex operation.
Operating Voltages: VBUS: 5V ~ 48V (typ.), VCONN: 5.5V (max) ~ 3.0V (min.)
Power consumption: under 37.5mW.
Current delivery capacity: 5A (max.)
Compliant with USB Power Delivery Specification Rev3.1
Storage and Operation temperature
Storage Temperature: Intel Thunderbolt Standard -20~85°C ambient.
Operation Temperature: Intel Thunderbolt Standard 0~50°C ambient.
