| 產品內容
Supports TBT Gen3, Gen4 or Gen5 full duplex high speed transmission.
Supports USB4 Gen2/Gen3/Gen4 full duplex high speed transmission.
Supports 1-CH USB3.2 Gen1 or Gen2 or supports 2- CH USB3.2 Gen2 full duplex high speed transmission.
Supports 1-CH USB2.0 half duplex transmission.
Support DP2.1, 4-lane DisplayPort video signal transmission, DP alternate mode.
Dual-protocol support for TBT mode (PCI Express and DisplayPort) and can be used for daisy chaining devices.
Triple -protocol support for USB4 mode (USB, PCI Express and DisplayPort*) and can be used for USB4 daisy-chaining devices.
Plug flip-able use
Thin cable design, OD=5.2mm
Compliant with USB Power Delivery Specification Rev3.1 Maximum power delivery capacity up to 5A
| 產品規格
General Specification
o Length: 1.5 meter / 1.8 meter / 2.0 meter
o Connector: LOTES Type-C connector or compatible
o Color: Black
Electrical Specification
· Transmission data rate:
Thunderbolt: Thunderbolt Gen2/Gen3/Gen4/Gen5 full duplex operation.
DP: DP2.1, 4-lane DisplayPort video signal transmission, DP alternate mode
(MFDP).
USB: 1-CH USB3.2 Gen1 or Gen2 full duplex operation.
2-CH USB3.2 Gen2 full duplex operation.
USB4 Gen2/Gen3/Gen4 full duplex operation.
1-CH USB2.0 half duplex operation.
· Operating Voltages: VBUS: 5V – 48V (typ.),
VCONN: 5V (typ.)
· Power consumption: 1.4W (typical)
· Current delivery capacity:
5A (max.)
· Compliant with USB Power Delivery
Specification Rev3.1
Storage and Operation temperature
o Storage Temperature: Intel Thunderbolt Standard -20~85°C ambient.
o Operation Temperature: Intel Thunderbolt Standard 0~40°C ambient.
