Echo 21 TB5 SuperDock Thunderbolttechnology Post

Key Features

• One Cable Peripheral Connection – Plug all your peripherals into the Echo dock’s 21 interfaces and connect your computer to the dock with the included Thunderbolt 5 cable.

• Two Thunderbolt 5 Ports for Peripherals – Support Thunderbolt 5, 4, and 3 devices; USB4 and USB 3 devices; plus displays.

• M.2 NVMe SSD Slot – Add up to 8TB of internal storage (SSD sold separately) with up to 3300 MB/s performance — perfect for content creation, media libraries, and backups

• 10 Gigabit Ethernet Port – Link to an Ethernet network or NAS at 10 Gigabit speed! Also supports 5Gb, 2.5Gb, and 1Gb Ethernet link speeds.

• 10 Gbps USB-C Port (with 15W Charging) – Provides 15W of power for operation or charging; supports super-fast 10 Gbps USB NVMe SSDs at full speed.

• 10 Gbps USB-C Ports (with 7.5W Charging) – Provide 7.5W of power each for operation or charging; support 10 Gbps USB NVMe SSDs at full speed.

• 10 Gbps USB-A Ports (7.5W) – Provide 7.5W of power each; support 10 Gbps USB NVMe SSDs at full speed.

• Video Output (HDMI) Port – Connect an HDMI display directly, no adapter required.

• Video Output (DisplayPort) Port – Connect a DisplayPort display directly, no adapter required.

• Connect as Many as Three Displays via Thunderbolt – Depends on your computer; see product page Tech Specs for details.

• Supports 1080p, 1440p, 4K, 5K, 6K, and 8K Displays, @ up to 500Hz – Depends on your computer; see product page Tech Specs for details.

• Charges Your Laptop – Provides 140W through the included Thunderbolt 5 cable to power and charge your laptop.

• Hi-res Audio I/O Support – 3.5mm stereo headset jack, separate left/right channel RCA line out jacks deliver a clean signal to powered speakers or an amplifier, plus a 3.5mm microphone jack.

• Fast UHS-II SD and microSD Card Slots – Support 320 MB/s read speeds with UHS-II cards.

• Mac Compatible – Supports all M series Macs, and Intel Macs with Thunderbolt 3 ports.

• Windows Compatible – Supports Windows computers with Thunderbolt 5 or 4, or USB4 ports.

• Chromebook Compatible – Supports Chrombeook computers with Thunderbolt 5 or 4, or USB4 ports.

• M Series iPad Pro Compatible – Supports M series iPad Pro tablets.

—Thunderbolt 5 – Tomorrow’s Performance, Today—
Presenting the Echo 21 Thunderbolt 5 SuperDock — our most powerful and expandable dock ever — featuring superfast SSD internal storage capability and built-in 10GbE networking. Transform a single cable connection from your computer into two Thunderbolt 5 peripheral ports, one NVMe SSD slot, one 10Gb Ethernet port, nine 10 Gbps USB ports, two video output ports, and more! With 80 Gbps of bi-directional data speed — twice as fast as Thunderbolt 4 — and 120 Gbps for higher display bandwidth, you'll revolutionize your productivity.

—Connect Your Peripherals and Power Your Laptop with One Thunderbolt 5 Cable—
Echo 21 Thunderbolt 5 SuperDock links connected Thunderbolt devices, monitor(s), USB peripherals, powered speakers, and Ethernet cable to your computer with a single Thunderbolt 5 cable. Got a laptop? Keep its power adapter in your bag — the SuperDock will power it with 140W of charging power. When it’s time to leave, just unplug the Thunderbolt cable, grab your computer, and go.

—Internal SSD Expansion Slot – Add 8TB of NVMe Storage at up to 3,300 MB/s—
Add up to 8TB of high-speed SSD storage (SSD sold separately) directly inside the dock —no external storage device required. Installation is simple: remove the bottom panel, insert the SSD, and secure the cover. Once installed, access and transfer data at up to 3300 MB/s. Ideal for pro content creation, application storage, large media libraries, and Time Machine backups.

—Integrated HDMI and DP Display Support—
Echo 21 Thunderbolt 5 SuperDock features video output ports for HDMI and DisplayPort displays, enabling you to connect either an up to 8K @60Hz HDMI monitor or a 4K @144Hz DisplayPort monitor.

— Blazing-fast 10GBASE-T Access—
Echo 21 Thunderbolt 5 SuperDock supports demanding workflows with built-in 10 Gigabit Ethernet, enabling connection to 10GbE infrastructure using cost-effective Cat 6 or Cat 6A copper cabling (up to 55 or 100 meters, respectively) – eliminating the need for (and expense of) a separate adapter. The dock also supports 5 Gbps, 2.5 Gbps, and 1 Gbps link speeds when connected to switches or NAS devices without 10GbE support.

—High Resolution Audio Support—
Echo 21 Thunderbolt 5 SuperDock features a hi-res Audio Codec (coder-decoder) that supports the dock’s audio I/O jacks with high quality, lossless audio.

—Dual Downstream Thunderbolt 5 Ports for Comprehensive Connectivity—
Echo 21 Thunderbolt 5 SuperDock incorporates three Thunderbolt 5 ports. One connects to and powers your computer — ideal for laptops with only one or two Thunderbolt ports, since it handles charging and data through a single connection. The other two support Thunderbolt 5, 4, and 3 devices — as well as USB4 and USB 3 peripherals — and each provides 15W for demanding bus-powered devices. If supported by your computer, you can also connect one, two, or even three additional displays.

—Powerful 10 Gbps USB-A and USB-C Ports—
Echo 21 Thunderbolt 5 SuperDock delivers powerful USB 3 connectivity with four 10 Gbps USB-A ports, and five 10 Gbps USB-C charging ports; all ports support super-fast 10 Gbps USB NVMe SSDs at full speed. The Echo 21 doesn’t skimp on power either. Each port provides 7.5W (or 15W) to ensure that drives with higher peak power requirements mount and operate reliably. An added benefit of the USB-C ports is they support device charging even when the computer is off, asleep, or disconnected.

—Thunderbolt Certified for Mac, Windows, Chromebook, and iPad Pro—
Echo 21 Thunderbolt 5 SuperDock is certified for use with Apple M series Macs; Thunderbolt 3 Intel Macs; Thunderbolt 5 and most Thunderbolt 4 Windows computers; Thunderbolt 5 and 4 Chromebook computers; and M series iPad Pro.

—More Pixels: Drive 4K, 5K, 6K, and up to 8K Displays via Thunderbolt
Depending on your computer’s graphics capability and whether a DisplayPort or HDMI monitor is connected to one of the dock’s built-in display outputs, the Echo dock’s Thunderbolt ports can support as many as three displays — at 4K, 5K, or 6K resolution, and up to 8K.

—Charge It Up and Leave the Power Adapter In Your Backpack—
Connected to your laptop computer with the included Thunderbolt 5 cable, Echo 21 Thunderbolt 5 SuperDock provides up to 140W of power (Power Delivery), enabling it to power and charge your computer while connected, even when not in use, allowing you to leave your computer’s charger packed away.

—Fast UHS-II SD and microSD 4.0 Card Readers—
The included SD and microSD card slots are compatible with SD, SDHC, and SDXC; and microSD, microSDHC, and microSDXC memory cards, respectively, and support 320 MB/s read speeds with UHS-II SDXC and microSDXC cards to quickly offload images and video files.

—Connect It Securely: Thunderbolt 5 Cable and ThunderLok Included—
The included Thunderbolt cable delivers Thunderbolt 5’s full bandwidth and power delivery performance, and is compatible with Thunderbolt 5, 4, and 3, and USB4 computers. A provided ThunderLok connector lock helps prevent accidental disconnections from the SuperDock.

—Secure it Physically: Kensington Lock Ready—
Secure the Echo dock with a Kensington lock (sold separately). The dock is compatible with Standard, MicroSaver, and MicroSaver 2 locks.
