Blackmagic eGPU

  • Category: Dock, eGFX
BlackMagic Design
Operating System:
Self or Bus Powered:
Self Powered
Number of Thunderbolt Ports:
Thunderbolt Version:
Thunderbolt 3

The Blackmagic eGPU features a Radeon Pro 580 graphics processor that accelerates professional applications such as DaVinci Resolve and makes 3D games and VR look more realistic and play at much higher frame rates. It’s also an expansion hub to power and charge your laptop, plus you get docking support for 2 additional displays via HDMI and Thunderbolt 3. Four additional USB 3.1 ports are included

- Product type: eGPU turnkey solution with graphics
- Power supply configuration: Internal
- Power rating: 315W max
- Charging support: 85W max
- No of Thunderbolt Controllers: 2 both with 85 watt charging capability along with all other Thunderbolt3 USB Type C capabilities
- No of USB 3 Ports: 4 upporting USB 3.1 Gen1 data rates and providing a charging current up to 1.5A each.
- LAN interface: None
- Audio interface: None
- HDMI out: 4K at 4096x2160 at 60 hz
- TYPE C displays and Thunderbolt 3 ports support Video display out in addition to HDMI port.

Supported Operating systems and Graphics Card:

macOS: High Sierra 10.13.6 and later
Graphics Cards Supported:
- AMD 580 Pro
Fixed GPU installation using AMD only

Microsoft Windows and Windows based PCs are not compatible and not supported at this time
